• 8 x 10/100/1000BASE-T PoE ports • 2 x SFP ports • Supports 802.3at Power over Ethernet • Comprehensive Layer 2 features including Link Aggregation, Port-based Q-in-Q, and VLAN trunking • Enhanced network security with IP-MAC Port-Binding (IMPB), Access • Control List (ACL), and IEEE 802.1X • Embedded 6 kV surge protection, sub-50 ms recovery ERPS, and Dying Gasp provide optimal reliability
The DGS-1210ME Series Metro Ethernet Switches feature a variety of port configurations, including 10/100/1000BASE-T RJ-45 ports, 1G SFP ports, and 10G SFP+ ports for increased network bandwidth. Surge protection, advanced Layer 2 functions, and a suite of security and management tools make the DGS-1210ME Series Metro Ethernet Switches ideal for Metro Ethernet applications.
Efficient and Resilient
For mission critical environments, the DGS-1210ME Series Metro Ethernet Switches support IEEE 802.1D 2004 edition, 802.1w, and 802.1s Spanning Tree Protocols (STP). The switches also support IEEE 802.3ad link aggregation, increasing bandwidth and redundancy for higher availability. This series furthermore features IEEE 802.1p Quality of Service (QoS), allowing for real-time traffic classification into Weighted Round Robin (WRR) and strict priority levels mapped to 8 queues. Advanced traffic classification parameters allow the network to be tuned for flexible configurations for specific multimedia applications such as VoIP or IPTV.
Security & Authentication
The DGS-1210ME Series supports IEEE 802.1X port-based/host-based access control, guest VLAN, and RADIUS/TACACS+ authentication for strict access control to the network. The IP-MAC-Port Binding (IMPB) feature allows administrators to further enhance user access control. The built-in D-Link Safeguard Engine™ protects the CPU from broadcast, multicast, and unicast flooding. In addition, the Access Control List (ACL) feature enhances network security and switch performance.
Multicast Applications
The DGS-1210ME Series features a full set of L2 multicast functions, including IGMP snooping, IGMP filtering, fast leave, and multicast traffic configuration for specific ports. With L2 multicast support, the DGS-1210ME Series is ready and capable of handling growing IPTV applications.
Management Capabilities
A user-friendly web interface gives administrators access to advanced management features such as DHCP auto-configuration, allowing central management of device configurations. The switches support Link Layer Discovery Protocol (LLDP), which advertises the device’s capabilities and identity to the local network, allowing administrators to better manage their network topology. Each port also supports cable diagnostics to troubleshoot cable length and functionality problems remotely.
Traffic & Bandwidth Control
Integrated bandwidth control allows network administrators to define the throughput levels for ingress and egress bandwidth. It provides a minimum granularity of 64 Kbps for ingress port and flow-based bandwidth control, and a minimum granularity of 64 Kbps for egress queue bandwidth. The DGS-1210ME Series also supports traffic control, which optimizes overall performance, while port mirroring helps administrators perform traffic diagnostics and track network performance.
Need help?
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible.
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
Customer Support
D-Link provides 24x7 LiveChat/Hotline Tech Support
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
Tech Specifications
Hardware
PoE Power Budget
78 W
Aggregation
802.1AX Link
802.3ad Link
8 x Link Aggregation Group Per Device
8 x Max Port Per Link Aggregation Group
Console Port
FAN
Fanless
Wireless
Switching Capacity
20 Gbps
Maximum Forwarding Rate
14.88 Mpps
MAC Address Table Size
16K
Control
802.3x Flow
Head-of-line (HOL) Blocking Prevention
Yes
Spanning Tree Protocol (STP)
IEEE 802.1D STP
IEEE 802.1s MSTP
IEEE 802.1w RSTP
Jumbo Frame
9,216 Bytes
IGMP Snooping
Max 1024 IGMP Snooping Groups
Interfaces
8 x 10/100/1000BASE-T PoE ports
2 x 1000M SFP
4 x Max IP Interface
General
Max Power Consumption
101.7 W (PoE on)
17.9 W (PoE off)
Standby Power Consumption
10.3 W/100V
11.1 W/240V
Store & Forwarding Forwading
Yes
Power Input
100 to 240 V AC
CPU Speed
400MHz
DRAM Size
256MB
Packet Buffer Size
1.5Mbits
Flash Memory Size
32 MB
Physical
Dimensions
280 x 180 x 44 mm(11.02 x 7.08 x 1.73 in)
Weight
1.92 kg
Maximum Heat Dissipation
307,703 BTU/hr
Acoustic
0 dB
MTBF
315,336 hours
Temperature
Operating: -5 to 50° C (23 to 122° F)
Storage: -20 - 70 ˚C
Humidity
Operating: 0% - 95% RH
Storage: 0% - 95% RH
Operating Altitude
1500 m
