DGS-1048: SWITCH KHÔNG QUẢN LÝ 10/100/1000 48 CỔNG

Switch Gigabit Độc Lập Không Quản Lý 48 Cổng 10/100/1000Base-T (Vỏ kim loại)

Switch Gigabit Ethernet DGS-1048 mang đến giải pháp nâng cấp hệ thống mạng hiện tại lên chuẩn 1000Mbps với hiệu năng cao, chi phí tối ưu, vận hành mượt mà và dễ dàng triển khai. Toàn bộ 48 cổng đều hỗ trợ tính năng tự động nhận diện cáp thẳng/chéo (Auto MDI/MDIX), cho phép người dùng thiết lập nhanh chóng theo cơ chế cắm và chạy (plug-and-play) mà không cần quan tâm đến chuẩn cáp. Bên cạnh đó, nhờ tích hợp công nghệ tiết kiệm năng lượng tiên tiến, DGS-1048 giúp giảm thiểu điện năng tiêu thụ, trở thành một giải pháp hạ tầng mạng thân thiện với môi trường.

  • 48 cổng RJ45 tốc độ 10/100/1000Mbps.
  • Công nghệ tiên tiến giúp tối ưu và tiết kiệm điện năng.
  • Hỗ trợ tự động học địa chỉ MAC và tự động nhận diện cáp (Auto MDI/MDIX).
  • Thiết kế vỏ thép tiêu chuẩn 19-inch, dễ dàng lắp đặt vào tủ rack.

Công Nghệ Xanh (Green Technology)
Mẫu switch gắn tủ rack 48 cổng Gigabit DGS-1048 được ứng dụng các công nghệ tiết kiệm năng lượng đột phá. Sản phẩm tuân thủ nghiêm ngặt tiêu chuẩn RoHS của Châu Âu về việc hạn chế sử dụng vật liệu độc hại. Ngoài ra, phần lớn vật liệu đóng gói của thiết bị đều được thiết kế để có thể tái chế.

Hiệu Năng Cao (High Performance)
Tất cả 48 cổng kết nối đều là chuẩn Gigabit RJ-45, đáp ứng băng thông cho các tập tin dung lượng lớn, đồng thời tương thích ngược hoàn toàn với các thiết bị Ethernet 10Mbps và 100Mbps. Sở hữu kiến trúc chuyển mạch không tắc nghẽn (non-blocking), DGS-1048 có khả năng chuyển tiếp và lọc gói tin ở tốc độ tối đa, đảm bảo thông lượng truyền tải cao nhất. Việc hỗ trợ khung Jumbo 12KB giúp cải thiện đáng kể hiệu suất khi xử lý dữ liệu lớn. Kết hợp cùng tính năng kiểm soát lưu lượng IEEE 802.3x cho chế độ Song công toàn phần (Full Duplex) và back pressure cho chế độ Bán song công (Half Duplex), thiết bị giúp triệt tiêu tình trạng tắc nghẽn mạng, đảm bảo khả năng vận hành ổn định. Đây là lựa chọn lý tưởng để nâng cấp hạ tầng lên chuẩn Gigabit trong khi vẫn bảo vệ trọn vẹn các khoản đầu tư trước đó của doanh nghiệp.

Dễ Dàng Sử Dụng (Easy to Use)
Các tính năng tự động của dòng switch gigabit này giúp quá trình triển khai trở nên đơn giản, cắm là chạy và không đòi hỏi cấu hình phức tạp. Tính năng Auto MDI/MDIX loại bỏ hoàn toàn sự phụ thuộc vào cáp chéo. Đồng thời, chức năng đàm phán tự động (auto-negotiation) trên mỗi cổng sẽ tự động nhận diện tốc độ liên kết của thiết bị mạng (10, 100 hoặc 1000 Mbps) để tinh chỉnh thông minh, mang lại sự tương thích và hiệu năng hoạt động tối ưu.

Hardware
Switching Capacity
  • 104 Gbps
Transmission Method
  • Store-and-forward
MAC Address Table
  • 16K entries
Static MAC Addresses
  • 256 entries
Maximum 64 Byte Packet Forwarding Rate
  • 77.4 Mpps
Packet Buffer Memory
  • 12 Mbits
CPU Memory
  • DDR3 128 MB
Flash Memory
  • 32 MB
PoE Capable Ports
  • Ports 1 to 48
Power Budget
  • 370 W
General

Interfaces
  • 48 10/100/1000BASE-T PoE
  • 4 100/1000 Mbps GbE/SFP combo ports
Port Standards
  • IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
  • IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
  • IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic
  • IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
  • IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic
  • IEEE 802.3az Energy Efficient Ethernet (EEE)
  • IEEE 802.3x Flow Control
  • IEEE 802.3af/at compliance (for PoE ports)
Network Cables
  • UTP Cat. 5, Cat. 5e (100 m max.)
Duplex Mode
  • Full/Half-duplex for 10/100 Mbps
  • Full-duplex for 1000 Mbps
Media Interface Exchange
  • Auto MDI/MDIX adjustment for all twisted-pair ports
Certifications
  • EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CQC (only for specific models)
  • Safety: CB, UL, BSMI, LVD, CQC (only for specific models)
MTBF
  • 236,406 hours
L2 Features
  • MAC Address Table
    • 8K entries
    • 16K entries (DGS-1210-52/52MP only)
  • IGMP Snooping
    • IGMP v1/v2 Snooping
    • IGMP v3 awareness
    • Supports 256 IGMP groups
    • Supports at least 64 static multicast addresses
    • IGMP per VLAN
    • Auto IGMP
    • Supports IGMP Snooping Querier
  • Loopback Detection
  • 802.3ad Link Aggregation:
    • DGS-1210-10/10P/10MP: Supports maximum 4 groups per device and 8 ports per group
    • DGS-1210-20/26/28/28P/28MP: Supports maximum 8 groups per device and 8 ports per group
    • DGS-1210-52/52MP: Supports max 16 groups per device and 8 ports per group
  • LLDP
  • LLDP-MED
  • Jumbo Frame
    • Up to 10,000 bytes
  • Spanning Tree Protocol
    • 802.1D STP
    • 802.1W RSTP
    • 802.1s MSTP
  • Flow Control
    • 802.3x Flow Control
    • HOL Blocking Prevention
  • Port Mirroring
    • One-to-One
    • Many-to-One
    • Supports Mirroring for Tx/Rx/Both
  • Multicast Filtering
    • Forwards all unregistered groups
    • Filters all unregistered groups
  • Configurable MDI/MDIX
    • MLD snooping v1/v2 (256 groups)
VLAN
  • 802.1Q
  • VLAN Group
    • Max. 256 static VLAN groups
  • Configurable VID from 1 - 4094
  • Asymmetric VLAN
  • Auto Voice VLAN
    • Max. 10 user-defined OUI
    • Max. 8 default OUI
  • Auto Surveillance VLAN
Quality of Service (QoS)
  • 802.1p Quality of Service
  • 8 queues per port
  • Queue Handling
    • Strict
    • Weighted Round Robin (WRR)
  • Bandwidth Control
    • Port-based (ingress/egress, min granularity 10/100/1000 is 16 Kbps)
  • QoS based on:
    • 802.1p priority queues
    • DSCP
    • MAC address
    • EtherType
    • IP address
    • Protocol type
    • ToS
    • IP preference
    • IPv6 Traffic Class
    • TCP/UDP port
L3 Features
  • IP interface
    • Supports 4 interfaces
  • IPv6 Neighbor Discovery (ND)
  • Static routing
    • 124 IPv4 static route entries
    • 50 IPv6 static route entries
Access Control List (ACL)
  • Max. 50 access lists
  • Max. 768 rules shared by IPv4, MAC, and IPv6
  • Each rule can only be associated with a single port
  • ACL based on
    • MAC address
    • 802.1p priority mask
    • VID mask
    • Source/destination MAC address mask
    • EtherType mask
  • IP address
    • Source/destination IP address mask
    • DSCP mask
    • Protocol type mask
    • TCP/UDP port number mask
  • IPv6 address
    • Source/destination IP address mask
    • DSCP mask
    • Protocol type mask
    • TCP/UDP port number mask
    • IPv6 traffic class mask
Security Features
  • Broadcast/Multicast/Unicast Storm Control
  • D-Link Safeguard Engine
  • Traffic segmentation
  • SSH v2
  • TLS v.1.3
  • DoS attack prevention
  • 802.1X Port-based Access Control
  • Port Security
    • Supports up to 64 MAC addresses per port
  • ARP Spoofing Prevention
    • Max. 127 entries
  • DHCP Server Screening
  • IP-MAC-Port Binding (Smart Binding)
    • ARP Inspection
    • Max. 256 entries
  • IPv4 Inspection
    • Max. 127 entries
  • IPv6 Inspection
    • Max. 63 entries
  • DHCP Snooping
    • Max. 512 entries
AAA
  • 802.1X Authentication
    • Supports local/RADIUS database
    • Supports port-based access control
    • Supports EAP, OTP, TLS, TTLS, PEAP
    • Max. 128 entries when using local database
    • IPv6 RADIUS server
    • Support MD5 authentication
OAM
  • Cable diagnostics
  • Factory reset
Management
  • Web-based GUI
  • D-Link Network Assistant Utility
  • Compact CLI
  • Telnet Server
  • TFTP Client
  • Configurable MDI/MDIX
  • SNMP
    • Supports v1/v2c/v3
  • SNMP Trap
  • Backup/upgrade firmware
  • Smart Wizard
  • Upload/download configuration file
  • BootP/DHCP Client
  • System Log
    • Max. 500 log entries
  • SNTP
  • ICMP v6
  • IPv4/v6 Dual Stack
  • DHCP Auto Configuration
  • Time setting
    • SNTP
  • RMONv1
  • Trusted host
  • Dual image
  • Dual configuration
Green V3.0 Technology
  • Power Saving by:
    • Link Status
    • Time-based PoE: PoE ports can be turned on/off by port or system through schedule
    • System hibernation
    • Port shut off
    • Cable length detection
MIBs
  • RFC1212 Concise MIB Definitions
  • RFC1213 MIBII
  • RFC1215 MIB Traps Convention
  • RFC1493 Bridge MIB
  • RFC1157, RFC2573, RFC2575, RFC2576 SNMP MIB
  • RFC1442, RFC1901, RFC1902, RFC1903, RFC1904, RFC1905, RFC1906, RFC1907, RFC1908, RFC2578, RFC3418 SNMPv2 MIB
  • RFC271, RFC1757, RFC2819 RMON MIB
  • RFC2021 RMONv2 MIB
  • RFC1398, RFC1643, RFC1650, RFC2358, RFC2665 Ether-like MIB
  • RFC2674 802.1p MIB
  • Interface Group MIB
  • RFC2618 RADIUS Authentication Client MIB
  • RFC4022 MIB for TCP
  • RFC4113 MIB for UDP
  • RFC2389 MIB for Diffserv.
  • Private MIB
  • PoE MIB
  • DDP MIB
  • LLDP-MED MIB
RFC Standards
  • RFC791 IP
  • RFC768 UDP
  • RFC793 TCP
  • RFC792 ICMPv4
  • RFC2463, RFC4443 ICMPv6
  • RFC826 ARP
  • RFC1321, RFC2284, RFC2865, RFC2716, RFC3580 Extensible Authentication Protocol (EAP)
  • RFC2573 SNMP Applications
  • RFC2461, RFC4861 Neighbor Discovery for IPv6
  • RFC2462, RFC4862 IPv6 Stateless Address Autoconfiguration (SLAAC)
  • RFC2464 IPv6 over Ethernet and definition
  • RFC4291 IPv6 Addressing Architecture
  • RFC2893, RFC4213 IPv4/IPv6 dual stack function

Physical
Power Input
  • 100 to 240 V AC 50/60 Hz internal universal power supply
Maximum Power Consumption (PoE enabled)
  • 478.9 W/100 V • 454.1 W/240 V
Maximum Power Consumption (PoE disabled)
  • 54 W/100 V
  • 54.4 W/240 V
Standby Power Consumption
  • 32 W/100 V
  • 31.6 W/240 V
Acoustics
  • High speed: 52.4 dB(A)
  • Low speed: 47.6 dB(A)
Heat Dissipation
  • 1634.01 BTU/hr (100 V)
  • 1549.29 BTU/hr (240 V)
Fans
  • 3
Operating Temperature
  • -5 to 50°C (23 to 122°F)
Storage Temperature
  • -20 to 70°C (-4 to 158°F)
Operating Humidity
  • 0% to 95% relative humidity
Storage Humidity
  • 0% to 95% relative humidity
Dimensions (L x W x H)
  • 440 x 430 x 44 mm (17.32 x 16.93 x 1.73 in)
Weight
  • 6.26 kg (13.80 lbs)
